Teltonika Networks
PR1KCL28 COMBO QUAD Mobil/GNSS SMA Tető Antenna
PR1KCL28 COMBO QUAD Mobil/GNSS SMA Tető Antenna
| Tulajdonság | Érték |
|---|---|
| Csatlakozás | 5 x RG174, 3000 mm | 5 x SMA Male csatlakozó |
| Típus | LTE MIMO 4x4 + GPS |
| Sugárzási minta | Omnidirekcionális |
| GNSS Antenna | |
| Frequency Range | 1575.42-1610 MHz |
| Polarization | RHCP |
| Impedance | 50 Ω |
| LNA Gain | 28±2 dB |
| Supply Voltage | 3-5 VDC |
| Current Consumption | < 15 mA |
| LNA V.S.W.R | <2.0 |
| Connector | SMA Male |
| Cable | 1 x RG174, 3000 mm |
| LTE MIMO Antenna | |
| Frequency Range | 698-960/1710-2690 MHz |
| Polarization | Linear |
| Gain | 3 dBi |
| V.S.W.R | :<3.0 |
| Impedance | :50 Ω |
| Connector | 4x SMA Male |
| Cable | 4 x RG174, 3000 mm |
| Mechanical/Environmental | |
| Mounting Method | Screw |
| Operating temperature | -40 ⁰C to +85 ⁰C |
| Radome Ingress Protection rating | IP67 |
| Radome Material | ABS |
| Weight | 540g |
| RoHS Compliant | yes |
