| Tulajdonság |
Érték |
|
Mobilinternet
|
Nem támogatott |
|
WiFi
|
802.11 b/g/n/ac (WiFi 5) |
|
Ethernet
|
4 x 10/100/1000 Mbps |
|
SIM
|
Nem támogatott |
|
CPU
|
Qualcomm, 4 x ARM Cortex A7, 717 MHz |
|
Memory
|
256 MBytes Flash, 256 MBytes RAM |
|
Powering option
|
4pin power socket, 9-50 VDC |
|
Antenna connectors
|
2 x RP-SMA for WiFi, 1 x RP-SMA for Bluetooth |
|
Ethernet
|
4 x 10/100/1000 Ethernet ports:1 x WAN (configurable as LAN), 3 x LAN |
|
WiFi
|
IEEE 802.11a/b/g/n/ac 2.4GHz/5GHz, Access point (AP), Station (STA) |
|
Bluetooth
|
4.0 (Low energy) |
|
Inputs/Outputs
|
On 4pin socket:1 x Digital input, 1 x Digital open collector output |
|
Other
|
1 x USB host |
|
Status LEDs
|
2 x WiFi, 8 x Etherner, 1 x Power |
|
Operating temperature
|
-40 °C to 75 °C |
|
Housing
|
Aluminium housing with DIN rail mounting option and grounding capability |
|
Dimensions
|
115 x 32 x 95 mm |
|
Weight
|
355 g |
|
Operating system
|
RutOS (OpenWrt based Linux OS) |
|
Network protocols
|
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, PPPoE, DHCP, Telnet |
|
Routing
|
Static routes, Dynamic routes (BGP, OSPFv2, RIPv1/v2, EIGRP, NHRP), Routing rules |
|
VPN and tunneling
|
OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, WireGuard, ZeroTier |
|
Monitoring and management
|
WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS |
|
Connection monitoring
|
Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection |
|
Cloud solutions
|
RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx |
|
Hotspot
|
External/Internal Radius, MAC authentication, Walled Garden |
|
Supported Hotspot platforms
|
IronWiFi, HotspotSystem, Cloud4Wi, SAI + WiFi, MugiCloud, Purple.ai |
|
Services
|
DDNS, VRRP, Wake On Lan (WOL), WEB filter, UPNP, Network shares (Samba), Traffic Logging |
