VBR1 Ipari Rezgés- ütés- és 3 tengelyes dőlésérzékelő | RS485 + analóg kimenet | 2 m kábel
A Datasensing VBR1 Rezgés- ütés- és dőlésérzékelő detektálja a rendszer rezgéseit, azonosítja a rendellenes remegést vagy a rendellenes frekvenciát, lehetővé téve az azonnali karbantartást, amellyel pénzt takaríthat meg és elkerülheti a zavarokat.
| Tulajdonság | Érték |
|---|---|
| Operative range | ± 2g; ± 4g; ± 8g; ± 16g (selectable) |
| Resolution | 15,62mg @ ± 2g 31,25mg @ ± 4g 62,50mg @ ± 8g 125mg @ ±16g |
| Detection Axes | 3 (X, Y, Z) |
| Technology | MEMS |
| Output type | Digital + Analogue (I/V selectable) |
| Output Function | Vibration amplitude |
| Digital Output | RS485 57600 baud rate - 1 bit stop - no parity |
| Voltage Analogue Output | 0…5V / 0…10V (selectable) |
| Current Analogue Output | 4…20mA / 0…20mA / 0…24mA (selectable) |
| Operating Voltage | 19,2 … 28,8 Vdc |
| LED indicators | Green:Run mode Yellow:writing/programming memory Blue:transit of RS485 packet data Red:Interrupt active |
| Reverse Polarity Protection | Yes |
| Impulsive Overvoltage Protection | Yes |
| Power Consumption | < 1 W |
| Frequency Range | 0 … 400Hz |
| Digital Resolution | 16 bit @RS485 (complementary to 2) |
| Analogue Resolution | 12 bit |
| Load Resistor (Voltage) | 1kΩ … 1MΩ |
| Load Resistor (Current) | 100 … 500Ω |
| Dimensions | M18 |
| Housing Material | Stainless steel AISI316L (body) Grilamid (cable exit) |
| Connections | 2 m - 5 poles cable |
| Active Head Material | Stainless steel AISI316L |
| Operating temperature | -25°C …+70°C |
| Storage temperature | -30°C … + 90°C (without ice) |
| humidity | < 80% (without condensation) |
| Approvals | CE |
| Degree of protection | IP67 |
| Supplied Accessories | 2 x nuts |
| Dimensions | M18 |
| Operating Temperature | -25°C …+70°C |
| Humidity | < 80% (without condensation) |
| Mechanical Protection | IP67 |
