Teltonika Networks
Tartozékok Hálózati Eszközökhöz
| Tulajdonság | Érték |
|---|---|
| Input voltage | 100 - 240 VAC |
| Input frequency | 50/60 Hz |
| Input current | 2.5 A |
| Input connector | EU (Type C) |
| Output voltage | 50 VDC |
| Output current | 2.6 A |
| Output connector | 2-PIN, with cord end terminals |
| Weight | 500 g |
| Input voltage absolute maximum | 90 - 264 VAC |
| Input frequency absolute maximum | 47 - 63 Hz |
| Maximum input inrush current | 50 A |
| Output voltage absolute maximum | 47.5 - 52.5 VDC |
| Short circuit protection | ✓ |
| HIPOT (dielectric withstand test) | Primary to Secondary - 4242 VDC |
| MTBF | 50000 h |
| PSU efficiency standard | DoE Level VI |
| Certification | Safety;EN 60335-1;2012+A11;2014+A13;2017, EN60335-2-29;2004+A2;2010+A11;2018, EN 62233;2008 EMC; EN 55014-1;2017, EN 61000-3-2;2014, EN61000-3-3;2013, EN 55014-2;2015 (IEC 61000-4-2;2008, IEC 61000-4-4;2012, IEC 61000-4-5;2014, IEC 61000-4-6;2013, IEC 61000-4-11;2004+A1;2017) |
